MV7-AR

The MV7-AR tactical grade gyro-stabilised inclinometer delivers precision measurements of dynamic inclination, acceleration, and angular rate in challenging environments such as those encountered by heavy-duty construction, off-highway, agriculture, and trucking vehicles.

MV7-AR

expand_more

chevron_left

chevron_right

Sensor

High performance accelerometer
- 18 µg accelerometer bias instability
- ±16 g range
High performance Gyroscope
- 1000°/s range
- 1.5°/hr gyroscope bias instability
Attitude accuracy ±0.25°
Fully calibrated and temperature compensated from –40°C to +85°C

Operation

SAE J1939 communication protocol
Adjustable sampling rates up to 500Hz (100Hz default)
Triple power flexibility:
- 5V regulated
- 12V unregulated vehicle bus
- 24V unregulated vehicle bus
Single CAN command adjusts for any mounting orientation
Fully compliant to strict automotive and off-highway test standards

Package

Reinforced PBT Thermoplastic, Hermetically sealed
Steel compression limiters for additional ruggedization
Ingress protection IP68, IP69K
Highly compact and low profile
- 78.9 mm x 55.0 mm x 23.5 mm
- 107 grams
RoHS, REACH, CE, UKCA certifications

MV7-AR Data Sheet

Data Sheets

English

Certificates and Approvals

MicroStrain REACH-SVHC Compliance Declaration	Declaration of Conformity	English
MV7-AR Declaration of Conformity (EU)	Declaration of Conformity	English
MV7-AR Declaration of Conformity (UK)	Declaration of Conformity	English

M-Series CAD Model	CAD Step Files
M-Series CAN J1939 Configuration File	Software

MV7-AR
Performance Grade	Tactical Grade
Features	Accelerometer, Gyroscope
Bias Instability (Gyroscope)	1.5 °/hr
Bias Instability (Accelerometer)	18 μg
Communication Port Type	AMPSEAL 16 gold plated 4 pin
Update Rate	1-500 Hz
Weight	107
Weight	3.77 oz
Size	78.9 x 55.0 x 23.5
Size	3.1 x 2.2 x 0.93
Power Consumption	0.41 W
Input Voltage	+4.5 VDC Min, +36V VDC Max
Minimum Operating Temperature	-40 °C
Maximum Operating Temperature	85 °C
Minimum Operating Temperature	-40 °F
Maximum Operating Temperature	185 °F
MTBF	1658495 h
Sensing Range (Accelerometer)	16 g
Sensing Range (Gyroscope)	1000 °/s
Ingress Protection Rating	IP69K, IP68
Housing Material	Fiber-Reinforced PBT
Mounting Style	Screw Down

Product Code	Description
6212-3014	M-SERIES DEVELOPMENT KIT
6212-3016	M-Series Impact Shield
6212-3017	M-SERIES CABLE KIT
