R&D and End-of-Line Torque Testing for Small Electrical Motors

Making rotary control smoother than ever

HBK’s T210 shaft torque transducer delivers precise torque and rotational speed measurements in one compact sensor. Designed for test benches and robotic testing systems, it enables effortless, high-quality torque testing for end-of-line and R&D applications.


New feature! Now supports speed measurements up to 1024 impulses per revolution for even more precise results.

usp-icon

Efficiently measure torque, speed, angle, and power – all from one, high-performance sensor.

usp-icon

Compatible couplings make it simple to connect the T210 to your existing test bench setup.

usp-icon

Select from a wide range of torque measuring ranges and output signals to match your setup.

T210

Watch the on-demand webinar: Smarter Torque Testing with the T210

Discover how the T210 shaft sensor makes torque testing simpler, reliable, and more efficient for your R&D or end-of-line applications.

This session covers:

  • Why choose the T210 shaft sensor?
  • Key features and benefits
  • Customising the T210 for your test needs
  • Integrating of output signals into automation systems
  • Why the IO-Link option is the best choice for your torque testing
  • How to install into test benches with ready-to-fit couplings
Turning Volume Control Dial on a modern AV Receiver.

Use case: Rotary controls haptic testing

Haptic testing evaluates tactile feedback and mechanical properties of rotary knobs, switches, and dials to ensure satisfying user experiences.

These tests are crucial in industries like automotive, consumer electronics, and industrial controls, where tactile feel can define product quality.


The T210 supports:

  1. Torque measurement to assess rotation smoothness and consistency
  2. Torque feedback to precisely calibrate  resistance and tactile response
  3. Repeatability testing for long-term durability and performance

Use case: small electric motor testing

Torque sensors are vital in end-of-line testing of small electric motors, ensuring quality control and product performance with every test.


The T210 helps you:

  1. Verify performance under real load conditions, ensuring the motor meets  performance specifications across various operating conditions
  2. Detect faults or deviations that could impact the motor’s performance, whether they are caused by defective components, or wear and tear
  3. Measure output power to calculate motor efficiency, optimising the engine design while ensuring efficient operation
  4. Efficiently collect motor performance data for further analysis and design validation,  combining torque sensors in advanced test benches with data acquisition systems
A human hand holding a small electric motor gently between thumb and index finger, shown from the side. The camera is at eye level with the subject, displaying the hand and motor in profile. The background is soft and blurred, focusing attention on the lifelike details of the motor and the skin texture. The motor reveals fine copper coils, metallic parts, and precise mechanical features. Side lighting casts realistic shadows and highlights surface textures. Ultra-detailed, photorealistic style.

Now with IO-Link: smarter integration into your automation systems

The T210 now includes optional IO-Link for digital, bidirectional communication using standard 3-wire M12 cables. Connect quickly and easily with an IO-Link Master into fieldbus systems like EtherCAT and Profinet, or cloud platforms.

Understand your testing process like never before

The T210 uses IO-Link to deliver extensive real-time process, diagnostic, and statistical data directly to your IT-level applications.

T210 signal comparison_infografik – classic today and IO-Link tomorrow
T210

Order the T210 today

The T210 is available for order in the HBK online shop, if available in your country. See the product page for a link to the shop.

Need more information? Explore the T210 configuration options below, download the T210 files for CAD applications, or watch the free webinar for a full product introduction.

Any questions? Check out our frequently asked questions or contact us today to learn how HBK can enhance your testing productivity and efficiency.

T210 Couplings

chevron_left
chevron_right
Illustration of a T210 Installation two full coupling in isometric perspective

Illustration of a T210 Installation two full coupling in isometric perspective.

  • Shaft and coupling weight is supported by the bearings of the torque sensor itself
  • For standard and high-speed applications
Illustration of a T210 Installation two half coupling with free floating installation in isometric perspective

Illustration of a T210 Installation two half coupling with free floating installation in isometric perspective.

  • Free floating installation between two half couplings
  • Transducer is part of the joint shaft
  • Housing must be secured against rotation
  • For low speed applications
Illustration of a T210 Installation two full coupling in isometric perspective

Illustration of a T210 Installation two full coupling in isometric perspective.

  • Rigid connections are not able to compensate for any misalignment
  • Highly precise alignment on the rigid coupled part side is needed to minimise bending moments introduced into the shaft.
    Keep lenght as short as possible.
  • Consider reduced bearing lifetime

Shaft Torque Transducers – FAQ

Questions page we've collected and answered questions related to shaft torque sensors that you might have, too.
